DM042 Polarizing LCD Digital Microscope Windows Mac OS TV Compatible with Software
PRODUCT DESCRIPTION
Main Features
* Multifunctional connection type: supports output through USB port to PC; HDMI port to HD monitor; TV port to monitor. Also allow to work with the LCD screen directly, can take photo, video and playback etc., without any connection.
* High resolution: real 5MP resolution sensor, and up to 12MP resolution by digital zoom.
* High magnification: real 250x and up to 1200x by digital zoom.
Quick Details
Equipped with 5 mega pixels HD sensor and industrial lens, Toproview DM042 3D HDMI Digital Microscope features 4.3 inch screen, enabling users to view parts and components of the PCB clearly so as to improve the precision and efficiency of their soldering and repair work.
With multifunctional connection type: supports output through USB port to PC; HDMI port to HD monitor; TV port to monitor. Also allow to work with the LCD screen directly, can take photo, video and playback etc., without any connection.
LCD DIGITAL MICROSCOPE SPECIFICATIONS
MODEL | Model Name | DM042 |
| Connection | USB 2.0 to PC/HDMI port to monitor/TV port to monitor |
OPTICS | Polarizer | Yes |
| Magnification | Real 10x~250x(ba |
| Lens type | Optical glass |
| Focus range | Manual focus 0~110mm |
| Illumination | 8 adjustable white LED |
SENSOR | Sensor type | CMOS |
| Size | 5 megapixel |
| Resolution | 2590*1944 |
| Fr | 25 fps at 5MP output; |
FEATURES | Software | DigiCapture Pro for |
| Measurement function | Yes |
| Certification | CE/FCC/RoHS |
PHYSICAL | Dimensions | 18*34*30cm |
| Gross weight | 0.2kg |
| Stand | Comes with me |
PRODUCT ADVANTAGE
High quality sensor
With a high-quality sensor, model DM042 HDMI output polarizing LCD digital microscope has max 4032x3024 (12M 4032*3024) photo resolution which will provide clear and high-quality images. Moreover, the magnification can reach up to real 250X without interpolation and allows users to view the smallest solder joints on the display or on the external monitor connected with the microscope.
