Hair Scalp Detector Microscope with Screen Support to Take Photo Recording Measurement
PRODUCT DESCRIPTION
Quick Details
DM042 is the polarizer type LCD digital microscopes which with wide applications as the digital dermatoscope, hair scalp detector. Main product specification is with high resolution and multiple output methods for various applications. Supporting for 4 kinds of connection: through HDMI cable to output live into HDMI monitor; live viewing, capture, recording by the device itself; through TV cable to output live into TV monitor; through USB cable connecting to Windows, Mac computes or laptop and do some capture, store images and videos, measurements with attached PC software. The built-in adjustable polarizer allows to freely remove the unwanted reflection or glare from the object surface for a better contrast.
Main Features
* High magnification: real 250x and up to 1200x by digital zoom.
* High resolution: real 5MP and up to 12MP by digital zoom.
* Support handeld or destop working, works great for the mole, hair, scalp detector.
* With measurement function, will allow to do some mesaurement and test based on the users test sample.
* With polarizer built in, can get the sharp and clear photos for the hair and scalp testing.
LCD DIGITAL MICROSCOPE SPECIFICATIONS
|
MODEL |
Model Name |
DM042 |
|
|
Connection |
USB 2.0 to PC/HDMI port to monitor/TV port to monitor |
|
OPTICS |
Polarizer |
Yes |
|
|
Magnification |
Real 10x~250x(ba |
|
|
Lens type |
Optical glass |
|
|
Focus range |
Manual focus 0~110mm |
|
|
Illumination |
8 adjustable white LED |
|
SENSOR |
Sensor type |
CMOS |
|
|
Size |
5 megapixel |
|
|
Resolution |
2590*1944 |
|
|
Fr |
25 fps at 5MP output; |
|
FEATURES |
Software |
DigiCapture Pro for |
|
|
Measurement function |
Yes |
|
|
Certification |
CE/FCC/RoHS |
|
PHYSICAL |
Dimensions |
18*34*30cm |
|
|
Gross weight |
0.2kg |
|
|
Stand |
Comes with me |
FAQ
Q:Why choose Toproview dermatoscope?
Toproview: Developed for professionals yet economical for consumer or casual use.
Q:Why choose Toproview dermatoscope?
Toproview: If the selection of products do not meet your needs, custom options are available.
